VIMAGO™ HU

HDVI CT, Full-Featured Fluoroscopy and Digital Radiography

Gantry Size:

592 mm

Footprint:

Weight:

420 kg

Power* Input:

220v 32A

* Shielding requirements may vary from state to state. Please check your state's regulations to ensure compliance.

A single platform, full-body imaging solution.

Epica's HU* HDVI Platform

Since its inception, Vimago has had the highest spatial resolution and lowest noise of any 3D imaging modality. Now, contrast resolution has been substantially improved to rival any conventional CT. In fact, Vimago is capable of producing calibrated (Hounsfield Units) HU as used by radiologists to quantitatively measure density. *Hounsfield Unit calibration equivalent to conventional CT

HDVI (High Definition Volumetric Imaging) is a new hybrid technology in CT (Computed Tomography) that provides unprecedented diagnostic and interventional information for clinicians.

The Future of Point-of-Care Imaging is Here

VIMAGO™ HU ANATOMICAL APPLICATIONS

Hard Tissue

Soft Tissue

Angiography

  • Skulls — sinus, nasal, bulla, ears, brain, oncology, trauma

  • Orthopedics — stifles, elbows, hips, carpus/ tarsus, angular limb deformities, OCD, cartilage lesions, fractures

  • Dentistry

  • Spine — cervical, thoracic, lumbar

  • Tumors, Foreign Bodies

  • Thorax - Lung, Heart

  • Blood Vessels, Met Checks

  • Abdomen - Liver, Pancreas, Kidneys, Adrenals, GI, Shunts, Oncology

  • Blood Pathways

  • Lymph vessels

HDVI Multi-modality Platform

  • Proven to be clinically superior to radio-graphs

  • Diagnostically superior or equivalent to conventional CT

  • Study setup in minutes (not including patient positioning & anesthesia time).

  • Replaces Ultrasound in many cases

  • Replaces MRI in many cases

At no incremental cost to the practice...

At no incremental cost to the practice...

At no incremental cost to the practice...

Clear, Advanced Imaging Your Client Needs

VIMAGO™ HU PROCEDURAL APPLICATIONS

Diagnostic Fluoroscopy

Interventional Fluoroscopy

Surgical

  • Coughing

  • Swallow Studies

  • UG Studies

  • Shunts

  • Collapsing Tracheas

  • Biopsies

  • Endoscopy Guidance

  • Stents

  • SUB

  • Surgical Planning

  • Guided Biopsies

  • Minimally Invasive Surgeries

Fluoroscopy

Latest Platform Updates Include:

​​

  • Road Mapping

  • Digital Subtraction Angiography

  • Burst Mode

  • Dose Reduction Technology

Gracie Radiograph LAT R PELVIS.jpg

Digital Radiography

Vimago's built-in Digital Radiography system can be used in a single shot or scanning mode to allow an entire patient to be scanned in a single radiograph. Images may be taken at any angle.

HDVI

With Vimago™, you can view images in axial, sagittal, and coronal planes - because of this,  Vimago™ studies can be easier to read than regular radio-graphs.

Fluoroscopy

High-resolution images, auto-brightness/contrast & frame rates from 1-30 fps. Interventional imaging quality that exceeds C-Arm systems selling for considerably more.

Any orientation of the patient may be viewed and the gantry can move over the patient during a study with 3-dimensional orientation adjustment.

Helping your clients make a better-informed decision about their pets health every day.

HDVI

Choose the right imaging technology for you.

HDVI Differentiations

How is Epica's HDVI Technology Different than Conventional CT?

Conventional (CT) Computed Tomography

Compared to HDVI Technology

  • HDVI (High Definition Volumetric Imaging) is a new hybrid technology in CT (Computed Tomography) that provides unprecedented diagnostic and interventional information for clinicians.

  • Conventional CT samples densities within a patient’s anatomy, providing axial sliced data, leaving gaps in the data in-between each slice.

  • The data is reconstructed using interpolation, which works by using known data to estimate values at unknown points.

  • After the data had been interpolated it is rendered in axial and coronal data sets. The resolution is different on each side.

  • HDVI technology scans a solid volume of data at a time, resulting in gapless data, with no need for interpolation.

  • HDVI delivers a 3D map of densities with a spacial resolution that is the same in all three dimensions, with contrast equivalent to conventional CT.

  • This volume of data can provide resolution as small as 0.09mm which is about the thickness of a human hair.

  • Clinicians can see the data in any angle, thickness or orientation leading to superior diagnostic confidence.

CT Comparative Overview Coming Soon

Educational Resources

  • In our resource center, you will find an abundance of resources on a variety of topics from imaging to marketing support. Take a look now!

Scientific Reports | Case Studies | Videos | And More

At no incremental cost to the practice...

At no incremental cost to the practice...

Collaboration

Easily share DICOM studies safely with our Peregrine PACS. Query and retrieve all day long whether it is for a consult or to keep clients informed about their pets.

Fits any patient from a mouse to a mastiff (up to 50cm in patient thorax and table capacity of 450lbs)
